Discover the Red Spot series fuse holders by Eaton — engineered for industrial installations, fully compliant with BS88‑2 and IEC 60269‑2 standards, with current ratings from 20 A to 400 A.
Why Choose the Red Spot Fuse Holder Series?
-
Fully shrouded body for enhanced safety in industrial electrical cabinets.
-
High-dielectric strength material ensures durable, reliable performance.
-
Reliable contact system for superior conductivity and minimal heating.
-
Designed for the most demanding applications with BS88‑2 and IEC 60269‑2 certification.
Key Specifications at a Glance
| Specification | Value |
|---|---|
| Rated Voltage | Up to 690 V AC |
| Current Range | 20 A to 400 A |
| Conductor Size Range | 10 mm² to 240 mm² |
| Protection Index | IP20 |
| Ambient Operating Temp | Up to 40 °C |
Available Variants & Mounting Options
The Red Spot series offers multiple mounting and connection styles to suit various panel designs:
-
Front-connected versions
-
Back-stud connected versions
-
Combined front/back-stud connected versions
-
Flush-mounted back-stud versions
Colour options include black, white, grey, and green to assist with clear identification in control cabinets.
Accessories & Add-ons
Enhance functionality and safety with:
-
Padlockable inserts for lockout/tagout compliance
-
Warning carriers for visual fuse status indication
-
Terminal shrouds and fuse link adaptor kits to accommodate older fuse links or specialized formats
Applications & Use Cases
Ideal for industrial environments demanding safety and reliability, including:
-
Motor control centers, switchboards, and distribution panels
-
Manufacturing plants, process industries, and heavy-duty installations
-
Installations requiring BS88 and IEC 60269 standard fuse holders
-
High current installations up to 400 A with large conductor sizes up to 240 mm²
Benefits for Specifiers & Panel Builders
-
Simplified compliance with BS88-2 and IEC 60269-2 certification
-
Flexible installation options for faster panel build and retrofits
-
Reduced maintenance due to robust construction and reliable contacts
-
Improved safety through padlockable and warning carrier accessories
-
Broad current and conductor size range covers diverse industrial needs
Ready to specify or order? Contact us today for datasheets, pricing, and support to find the perfect Eaton Red Spot fuse holder for your industrial applications.
